automated Window Solutions

INNOVATIVE DESIGN

T9 innovative window system offers an unparalleled wide outdoor view with spans up to 4.5 meters. Featuring intelligent controls, superior thermal and acoustic insulation, it enhances comfort and energy efficiency. The 100mm-wide handrail boosts structural integrity, ensuring resilience against strong winds and storms, providing both aesthetic appeal and robust performance for contemporary living environments.

CONSTRUCTION SPECFICATION

• Profile thickness:1.8-3.0mm
• Frame Depth:168mm
• Mullion Width:21mm
• Sash Width:46mm
• Glass Standard:8G+18A+8G
• Mesh:Polyester Mesh

• Thermal Insulation - 3.5>Uw≥3.0W/㎡K
• Wind Resistant - 4.5>P3≥4.0kPa
• Sound Insulation(Rw) - 32dB
• Air tightness - LEVEL 7
• Water Tightness - 500≤ΔP<700pa

*Note: Performance based on glazing and size, the above conditions are laboratory theoretical data
